Potentiometer VISHAY® Multi Turn Wirewound – 534: 10 Turns

Features

• Bushing and servo mount designs available
• Linearity ± 0.25 %, down to 0.05 % on request
• Special resistance tolerances to 1 %
• Rear shaft extensions and support bearing
• Metric shaft available
• Dual gang configuration and concentric shafts
• High torque, center tap, slipping clutch on request
• Special markings and front shaft extensions

Electrical Specifications

Model: 534
Resistance range – standard values: 100 Ω to 100 kΩ
Capability range: 10 Ω to 200 kΩ
Standard tolerance: ± 5 %
Linearity (independent): ± 0.25 %
Noise: 100 Ω ENR
Rotation (electrical and mechanical): 3600° +10° -0°
Power rating (at 70 °C): 2.0 W

Insulation resistance: 1000 MΩ minimum 500 VDC
Dielectric strength: 1000 VRMS minimum 60 Hz
Absolute minimum resistance: Not to exceed linearity x total resistance or 1 Ω, whichever is greater
Temperature coefficient: 20 ppm/°C (standard values, wire only)
End voltage: 0.25 % of total applied voltage, maximum
Phasing: CCW end points – section 2 phased to section 1 within ± 2°
Taps: Center tap only
