RELAY SOLID STATE RELAY SSR FOTEK DC INPUT TO AC OUTPUT 15DA

General specification

Type: Standard type
Input voltage: 4 ~ 32 VDC
Peak voltage: 1200VAC min.
Output voltage: 24 ~ 380VAC
Turn off voltage: ＜3.5 VDC
Trigger current: 12.0mA max.
Control method: Zero cross
Leakage current: 5 mA max.
Response time: 8.3 ms（60Hz）
Input immunity: 2 KV（EN61000-4-4）
Isolation strength: 4 KVrms（EN60950/VDE0805）
Insulation strength: 100MΩ / 500VDC（EN60950/VDE0805）
Housing material: ABS（UL: 94V0）
Circumstance: -40℃ ~ +80℃；35 ~ 85％RH
